Black PTFE Teflon Fiberglass Fabric

Brand: WELLFLON
Materials: PTFE (Teflon), Fiberglass Fabric
Yarn Type: Filament Yarn/Texturized Yarn
Weave Type: Plain
Width Range: 1000~4000mm
Features: Non-stick, High-Temp Resistant
Temperature Resistance: -70°C ~ +280°C
Color: Brow/Black/White /Custom Color
Certification: FDA/LFGB/SGS/RoHS/UL
Quality Assurance: 1 Year

Black PTFE Teflon Fiberglass Fabric, also known as Teflon high temperature fabric, high temperature welding cloth, PTFE high temperature cloth, etc., is made of high-quality imported glass fiber fabric as the base material. Through unique processing technology, it is repeatedly fully impregnated and coated with high-quality PTFE (Teflon) resin to produce Teflon high temperature coated fabric of various thicknesses.

The Main Features of Black PTFE Teflon Fiberglass Fabric:

1. Used for low temperature -196 degrees and high temperature 300 degrees, it has weather resistance and anti-aging;

2. Non-adhesive: not easy to adhere to most substances, easy to clean;

3. Chemical corrosion resistance, strong acid, strong alkali, aqua regia and various organic solvents;

4. Low friction coefficient (0.05-1), a good choice for oil-free self-lubrication;

5. It has high insulation performance (small dielectric constant: 2.6, tangent below 0.0025), UV protection, anti-static

6. Good dimensional stability (elongation coefficient less than 0.5%) and high strength. It has good mechanical properties.

Application Range of Black PTFE Teflon Fiberglass Fabric:

1. Anti-stick lining, gasket, cover cloth and conveyor belt; according to different thickness, it can be used for conveyor belts, adhesive belts, sealing belts, etc. of various drying machines;

2. Welding cloth for plastic products welding and welding; plastic sheets, films, heat-sealed sheet lining tapes;

3. Electrical high insulation: electrical insulation tape base, spacers, gaskets, lining rings;

4. Microwave gaskets, oven sheets, food drying.

5. Solar laminator high temperature cloth (generally with a thickness of 0.25mm, 0.30mm, 0.35mm and a width of 2.2m)

The Common Specifications of Black PTFE Teflon Fiberglass Fabric are as Follows:

(Customized 0.05mm-1.5mm arbitrary thickness)

Main Specifications of Black PTFE Teflon Fiberglass Fabric:

Item	Color	Thickness	Max Width	Weight	Tensile Strength	Temperature
CWF-T0158	Brown/Black/White	0.08mm	1250mm	158±5g/m2	500/480N/50mm	-70~280 ℃
CWF-T0160	Brown/Black/White	0.08mm	1250mm	160±5 g/m 2	620/460N/50mm	-70~280 ℃
CWF-T0180	Brown/Black/White	0.08mm	1250mm	180±5 g/m 2	930/720N/50mm	-70~280 ℃
CWF-T0260	Brown/Black/White	0.13mm	1250mm	260±5 g/m 2	100/1000N/50mm	-70~280 ℃
CWF-T0275	Brown/Black/White	0.13mm	1250mm	275±5 g/m 2	1000/960N/50mm	-70~280 ℃
CWF-T0290	Brown/Black/White	0.13mm	1250mm	290±5 g/m 2	910/880N/50mm	-70~280 ℃
CWF-T0395	Brown/Black/White	0.18mm	1250mm	395±5g/m 2	1600/1600N/50mm	-70~280 ℃
CWF-T0415	Brown/Black/White	0.18mm	1250mm	415±5 g/m 2	1500/1500N/50mm	-70~280 ℃
CWF-T0490	Brown/Black/White	0.25mm	2800mm	490±5 g/m 2	2100/1800N/50mm	-70~280 ℃
CWF-T0510	Brown/Black/White	0.25mm	2800mm	510±5 g/m 2	2800/2700N/50mm	-70~280 ℃
CWF-T0660	Brown/Black/White	0.35mm	3200mm	660±5 g/m 2	2700/2600N/50mm	-70~280 ℃
CWF-T0680	Brown/Black/White	0.35mm	3200mm	680±5 g/m 2	2100/2200N/50mm	-70~280 ℃
CWF-T0780	Brown/Black/White	0.40mm	3500mm	780±5 g/m 2	2900/3100N/50mm	-70~280 ℃
CWF-T0820	Brown/Black/White	0.40mm	3500mm	820±5 g/m 2	3000/2900N/50mm	-70~280 ℃
CWF-T1150	Brown/Black/White	0.65mm	4000mm	1150±5 g/m 2	4200/4000N/50mm	-70~280 ℃
CWF-T1550	Brown/Black/White	0.90mm	4000mm	1550±5 g/m 2	6300/5800N/50mm	-70~280 ℃
CWF-T1650	Brown/Black/White	0.90mm	4000mm	1650±5 g/m 2	6150/5300N/50mm	-70~280 ℃
